17-4PH / 15-5PH Forgings Manufacturer in Mumbai, India

15-5PH Forgings, Stainless Steel 17-4PH Forging, UNS S17400 Forgings Dealer, 17-4PH Forgings, UNS S15500 Forgings, SS 15-5PH Forgings, 17-4PH Forgings Manufacture in Mumbai, India.

Niko Steel Engg LLP is one of the leaders in the manufacturing and supplying of premium quality 17- 4PH/ 15- 5PH Forgings. We also export our products. We manufacture our products following the standard procedures and so our products have been certified. We have products of different dimensions and also have provisions to manufacture custom based designs for our clients. We have several satisfied clients all over the world.

Duplex steel is also a type of steel. It is called duplex because it has two layers of microstructures. They are partially ferritic and partially austenitic. They contain the same composition as of steel. Some of the amounts of copper, nitrogen, and molybdenum are also added to give some specific qualities. The 17- 4PH/ 15- 5PH steel is much tougher than normal steel and has great corrosion resistance and is ductile. Hey, they are often used in machinery and marine applications.

Forging is a process when a metal or alloy is given a definite shape by applying pressure localization. The forging can be done by both cold and warm temperatures depending on the metals to be forged. The process is simpler and cheaper than fabrication and casting. The obtained final products are stronger and more reliable than the original metal. They can be used easily in stress environment conditions such as landing gear of aircraft, components of motors. The products can also be used in equipment used to tackle near the furnace as they can bear a high amount of heat also.

We manufacture the best quality SS 17- 4PH/ 15- 5PH Forgings considering Some standards include ASTM, ASME, BS, MSS, DIN and many more.. These products have to pass the following test to prove its reliability like PMI test, Ultrasonic test, Spectro test, and mechanical testing. Also our product passes various other tests such as stress tests, chemical and hardness test.

17-4PH Chain, SS 1.4542 Chain Link, 15-5PH Bow Shackle, 17-4PH Chain Link, ASTM B564 Alloy Forgings, 15-5PH Forgings Exporter in India.

15-5PH D Shackles, NACE MR0175 Forgings, 17-4PH Twist Link Chains, 15-5PH Forgings Stockholder, 15-5PH Bow Shackle, 17-4PH and 15-5PH Forgings Supplier.

We also ensure safe packaging and transportation of our products to prevent them from any kind of damage to these products during transportation. We also keep adequate stock of our products to fulfill any quantity of demands raised by our customers.

SS 17-4PH / 15-5PH Forgings Types
Specification of 17-4PH / 15-5PH Forgings
Standard : ASTM B564 / ASME SB564 AMS 5644
Dimension : ASTM,DIN, BS,GB, IS and all International Standards
Forged Between : 2300/1700ºF (1260/930ºC) and air cooled
Severe Reductions : Ingot breakdown, Roll forging, Drawing, Blocking and Backward extrusion- 2300ºF (1260ºC).
Moderate Reductions : Finish forging and upsetting- 2200ºF (1200ºC).
Slight Reductions : Coining, restriking and end upsetting- 2050ºF (1120º).
Type : Chain Link, D Shackle, Bow Shackle etc.
Other Properties of 17-4PH and 15-5PH Forgings
  • Equivalent Grades for 17-4PH / 15-5PH Forging
    STANDARD UNS WERKSTOFF NR.
    15-5PH S15500 1.4545
    17-4PH S17400 1.4542
  • 17-4PH / 15-5PH Forgings Chemical Composition
    Grade C Mn P S Si Cr Ni Cu Nb Ta
    17-4PH 0.07 1.00 0.04 0.03 1.00 15.00 - 17.50 3.00 - 5.00 3.00 - 5.00 0.15 - 0.45

    Grade C Si Mn P+S max Cr Ni Cu Cb Fe Mo
    15-5 PH 0.07 1.0 1.0 0.03P0.015S x 14.0-15.50 3.50-4.50 2.50-4.50 0.45 Bal 0.50
  • Mechanical Properties of 17-4PH / 15-5PH Forgings
    Element Density g/cm (3) Ultimate Tensile Strength Ksi (MPa) 0.2% Tensile Yield Strength Ksi (MPa) Elongation % in 2" (50mm) Hardness Rockwell C
    17-4PH 160 (1103) 145 (1000) 5.0 35 -

    Element Density g/cm (3) Density lb/in (3) Thermal Conductivity 70-212° Thermal Conductivity 70-932° Electrical Resistivity
    15-5PH 7.75 0.280 10.6 13.1 98

If you would like to inquire or place an order.
Call :+91 22 66362225/66662225/67432225

People also search for DIN 1.4542 / 1.4545 Forgings

17-4ph chain links suppliers in india, 15-5ph forgings suppiler in india, 17-4ph bow shackle, 15-5ph open die forging, 17-4ph d shackles, 15-5ph forgings suppliers in mumbai, 17-4ph shafting & bars, 15-5ph forgings dealer, 17-4ph crane hooks supplier, ss s15500 closed die forging, a wide range of the 15-5ph forgings price list, 17-4ph forgings price, 15-5ph forgings distributors, 17-4ph forgings exporter, din 1.4542 double loop chain, 15-5ph forgings products manufacturer in maharashtra, 17-4ph forged circles, astm b564 20 alloy forged discs, alloy s17400 d shackle with metric fine pitch, 17-4ph chain links, alloy din 20 bow shackle, alloy 1.4545 forged circles, uns s17400 forgings products supplier in india, 15-5ph seamless rolled rings.

Other 17-4PH / 15-5PH Forgings Types

Special Bow Shackle w/ No-Snag Pin, Open Die Forging, Step Shafts, Bolt Chain Shackle, Closed Die Forging, Long Link Chain, Anchor Shackle, Double Loop Chain, Mandrel Rings, Joining Shackle, Forged Circles, Lifting Chain, Shafting & Bars, Seamless Rolled Ring, Single Jack Chain, Crane Hooks, Forged Flat Bars, Forged Hollow Bars, Forged Circular Plates, Safety Chain Shackle, Forged Discs.

Quality Assurance of 17-4PH / 15-5PH Forgings

17-4PH and 15-5PH Forgings are manufactured and controlled to international standards such as ASTM, ASME, BS, MSS, EN, DIN or WERKSTOFFE. Our products undergo stringent quality tests before they are dispatched.
